Der factory supplies waterproof PVC coated polyester sheets for transport, construction, agriculture, storage and industrial protection. Select the base cloth, coating weight, finished size and reinforcement around real exposure, handling and fixing conditions.
Send the application, dimensions, quantity and expected exposure for a specification recommendation.
A PVC tarpaulin sheet should be specified as a complete covering system. Wind, movement, abrasion, temperature, seam layout and tie-down spacing often matter as much as the headline GSM.
For short-duration weather protection, indoor partitions, temporary pallet covers and applications where low handling weight is important.
For machinery, farm materials, site storage, market shelters and repeated seasonal use with appropriate UV stabilization and edge finishing.
For truck covers, trailers and cargo systems where vibration, flapping, sharp contact points and frequent installation can drive failure.
For demanding industrial covers, large enclosures, mining or construction protection and other projects requiring engineered reinforcement.
Unlike an unsupported plastic film, industrial PVC tarpaulin sheets use a woven polyester scrim to carry mechanical loads. PVC compounds on both faces provide waterproofing and can be adjusted for color, flexibility, UV exposure, surface finish and special functions.
Provides the exposed weather surface, color, cleanability and optional lacquer or functional treatment.
Yarn denier and weave density influence tensile strength, tear propagation, dimensional stability and weld behavior.
Completes the waterproof encapsulation and supports welding, abrasion resistance and balanced sheet construction.
A good tarp material must survive production, installation and repeated handling—not only pass a single laboratory value.
PVC encapsulation resists water penetration; welded seam design can create a dependable finished cover when drainage and penetrations are correctly managed.
Base-fabric denier, weave construction and coating adhesion are matched to wind, handling and tie-down loads rather than selected by weight alone.
Suitable PVC formulations and surface finishes help reduce wear from cargo edges, frame contact, dragging and repeated folding.
UV and weather-resistant options are available for exposed covers. Expected climate, color and service cycle should be defined before sampling.
Compatible PVC faces support hot-air or high-frequency joining, allowing large sheets, shaped covers and reinforced hems to be fabricated efficiently.
Options may include flame-retardant, anti-mildew, anti-static, low-temperature, blockout, matte, glossy or printable constructions.
The values below are a sourcing guide, not a one-size-fits-all data sheet. Final construction and tolerances should be confirmed on the quotation, technical data sheet and approved sample.
| Parameter | Typical options | Why it matters | Quotation note |
|---|---|---|---|
| Material structure | PVC coated or laminated high-tenacity polyester | Determines coating adhesion, flexibility, weldability and service class | State whether the order is finished sheets or roll material |
| Finished weight | Approx. 400–1200 gsm | Higher weight can add coating body and durability, but does not replace correct scrim selection | Confirm tolerance and test method |
| Thickness | Approx. 0.30–1.00 mm | Useful for clearance, folding and handling comparisons | Do not convert GSM to thickness without a sample or TDS |
| Base fabric | Typical 500D to 1300D polyester constructions | Controls tensile strength, tear performance and dimensional stability | Specify wind, load and tie-down conditions |
| Roll width | Common industrial widths around 1.0–3.2 m; wider options by project | Influences seam count, material yield and fabrication cost | Confirm usable coated width |
| Finished sheet size | Custom rectangular or shaped panels | Allows direct installation and reduced local fabrication | Provide finished size, not only cut size |
| Color / surface | Custom color matching; matte, glossy or application-specific surface | Affects appearance, cleaning, heat absorption, printing and repeat-order control | Use a physical swatch or color reference for approval |
| Edge system | Welded hem, rope hem, webbing reinforcement, corner patches | Transfers fixing loads into the body of the sheet | Include hem width and reinforcement material |
| Attachment points | Metal eyelets, D-rings, straps, loops, buckles or custom hardware | Determines installation speed and resistance to pull-out | State spacing, material and corrosion environment |
| Optional functions | UV, flame retardant, anti-mildew, anti-static, cold-resistant, blockout | Aligns the sheet with market rules and operating conditions | Provide the required standard and report format |
| Branding / packing | Logo printing, labels, barcodes, bags, cartons, pallets or bales | Supports distributor, project and private-label programs | Send artwork and packing specification before approval |
Mechanical values vary substantially by yarn, weave, coating process and total weight. Ask Der factory for a model-specific TDS and sample instead of comparing suppliers only by GSM.
Der factory can support buyers who need raw rolls, simple rectangular tarps or application-specific finished covers with reinforcement and branded packaging.
The right sheet construction changes with wind, movement, hygiene, flame performance, access requirements and expected service life.
Focus on tear strength, abrasion, controlled flexibility, welded seams, edge loading and dependable tie-down points.
Explore truck cover tarpaulin →
Temporary roofs, scaffold enclosures, weather screens and material covers require secure anchoring, drainage and wind-aware installation.
Explore construction tarps →
Fitted or loose covers can include shaped panels, access flaps, straps and abrasion patches around projecting components.
Explore heavy-duty PVC tarpaulin →
Hay, grain, feed, seasonal equipment and farm structures benefit from waterproofing, UV stabilization and practical handling weight.
Explore agricultural tarpaulin →
Converters and distributors can source repeatable PVC coated roll material for tarp fabrication, repair programs and regional stock.
Explore PVC coated polyester fabric →
Standard or custom finished sheets can combine easy cleaning, color choices, reinforced edges and application-specific attachment systems.
Explore vinyl tarps →Certification language should be tied to a specific material model, test method and production batch. Der factory can align test documentation with the agreed project specification.
Base fabric, PVC compound, color and hardware are checked against the approved order requirements.
Coating appearance, width, weight, color, welding and finishing details are monitored during production.
Applicable tensile, tear, adhesion, dimensional or functional tests can be defined using agreed ISO, DIN, EN or ASTM methods.
Finished dimensions, eyelet spacing, workmanship, printing, packing and quantity can be included in the inspection checklist.
Explain what is covered, indoor/outdoor use, climate, wind, abrasion and expected service cycle.
Provide length × width, shape, cut-outs, seam limits and whether dimensions are finished or cut size.
State preferred GSM, thickness or an existing sample; Der factory can recommend an alternative based on use.
List eyelet spacing, hem construction, rope, webbing, D-rings, straps and known high-load points.
Include UV, FR, cold flexibility, anti-mildew, anti-static, color, surface and required test method.
Quantity, destination, packaging, logo artwork, target schedule and repeat-order expectations.
Send your dimensions, application, target weight, quantity and finishing details. Der factory will review the load points, material construction, processing and packaging required for a practical quotation.
